4 axle rear dump semi trailer with 40 CBM capacity, 30,000 kg plus payload and steel tipper body. Built for heavy haulage. Request a quote today.
Rear dump semi trailer is a heavy-duty trailer for bulk material hauling. It moves sand, gravel, ore and construction waste across mines, quarries and construction sites.
The trailer supports a maximum payload above 30,000 kg. Cargo volume reaches 40 CBM per trip. Overall dimensions are 11280 x 2495 x 3970 mm, with customization available. Axle layouts cover 2, 3, 4, 5 or 6 axles. Tire options include 11.00R20, 12R22.5, 315 and 385 sizes.
The carriage and frame are fabricated from high-strength thickened steel plates. This construction resists wear, collision and deformation from hard bulk materials. A hydraulic rear tipping mechanism delivers fast lifting and smooth automatic unloading. The large tipping angle limits material residue inside the tank.
A dual line braking system and rugged chassis support off-road operation. Mechanical and air suspension are both offered, along with 2.0 inch (50mm) or 3.5 inch (90mm) kingpins. A three-axle or four-axle layout distributes cargo weight evenly to reduce tire abrasion.
Every unit passes strict production and quality inspection. Fleet operators choose this rear dump semi trailer for continuous heavy-duty work. It suits mining raw material transport, aggregate delivery and site clearing.
Contact us for pricing, axle configuration and customization details.
| Type | Semi-Trailer, Heavy Duty Vehicle |
| Max Payload | >30000 kg |
| Place Of Origin | China (Mainland) |
| Province | Guangdong |
| Use | Truck Trailer |
| Material | Steel |
| Size | 11280*2495*3970mm/Customization |
| Dimensions | 450 * 228 * 210 |
