Haul 40-60 tons in mines and quarries with this 3 axle dump semi trailer. Steel body, hydraulic tipping, 11280mm length. Request a quote today.
This 3 axle dump semi trailer is designed for mine and quarry operations. It hauls bulk material and heavy equipment using a hydraulic tipping system.
Payload capacity ranges from 40 to 60 tons, and maximum payload exceeds 30,000 kg. Axle configurations include 2, 3, 4, 5 and 6 axles. Overall dimensions are 11280 x 2495 x 3970 mm, and the platform layout can be customized.
The body is built from steel. Key stress areas are reinforced against compression, bending and impact. Integrated welding construction keeps the chassis rigid under frequent loading. An anti-rust coating protects the frame from rain, mud and salt fog, extending service life and lowering maintenance costs.
Suspension choices cover heavy-duty mechanical leaf spring and airbag suspension. A dual line braking system with a relay valve delivers balanced braking force on all axles. King pin options are 2.0 inch (50 mm) and 3.5 inch (90 mm). Tire sizes include 11.00R20, 12R22.5, 315 and 385.
This dump semi trailer suits mining, quarrying, construction and bulk aggregate hauling. It works with excavators, loaders and other loading equipment on site.
Customized axle counts, dimensions and platform layouts are available to match your fleet. Contact us for pricing, delivery times and detailed specifications on this 3 axle dump semi trailer.
| Type | Semi-Trailer, Heavy Duty Vehicle |
| Max Payload | >30000 kg |
| Place Of Origin | China (Mainland) |
| Province | Guangdong |
| Use | Truck Trailer |
| Material | Steel |
| Size | 11280*2495*3970mm/Customization |
| Dimensions | 450 * 228 * 210 |
