60 ton lowbed semi trailer for excavator delivery. 3 or 4 axle low loader, 11500-13000mm deck, 60T-150T payload. Request a factory quote today.
This 60ton lowbed semi trailer is built for excavator delivery and other heavy machinery transport.
Max payload options are 60T, 80T, 100T and 150T. Deck options measure 11500mm, 12500mm or 13000mm long. Axle configurations include 2, 3 or 4 axles rated at 13/16 ton. Mechanical suspension or air suspension is available. Tare weight ranges from 8000kg to 12800kg. Tire options include 12R22.5, 315/80R22.5 and 385/65R22.5.
The main beam uses Q690 steel for bending strength. The low bed platform is 3-5mm chequered plate with welded anti-slip ribs. This stops equipment from sliding during transport. The gooseneck frame uses reinforcement bars to raise effective load capacity. A manual or hydraulic ladder is optional. The king pin is 2.0 inch or 3.5 inch bolted type. Braking system includes a relay valve, spring brake chamber and two 45L air tanks. Two spare tire carriers are standard. ABS is optional.
A three axle low flatbed semi-trailer spreads load across 12 tires. A four axle version carries heavier loads under stricter road weight limits.
These low loader trailers move excavators, bulldozers, loaders, pavers and cranes. They also carry rail vehicles and mining or forestry machinery. The low center of gravity improves stability on uneven roads.
Contact our team for the factory price of this 60ton lowbed semi trailer. Custom specifications are supported.
| Model Number | Lowbed Semi Trailer |
| Type | Semi-Trailer |
| Max Payload | 60T/80T/100T/150T or Buyer's Request |
| Place Of Origin | China (Mainland) |
| Province | Guangdong |
| Use | Truck Trailer |
| Material | Steel |
| Size | 11500/12500/13000x3000x1750mm or customizable |
| Dimensions | 450 * 228 * 210 |
| Model | Lowbed Semi Trailer |
