3 axle low bed semi trailer with high-strength steel main beam, 60T to 150T payload, 13/16 ton axles and custom deck lengths. Contact us for pricing.
The 3 axle low bed semi trailer is built for hauling bulldozers, loaders and other heavy engineering machinery. It handles oversized, high-load cargo with a low deck and a stable platform.
Payload ratings for this 3 axle low bed semi trailer range from 60T to 150T, or as buyer's request. Deck size measures 11500/12500/13000 x 3000 x 1750 mm and can be customized. Three axles of 13/16 ton capacity share the load. Tare weight runs from 8000 kg to 12800 kg. Mechanical or air suspension is available. Braking uses six relay valves, spring brake chambers and two 45L air tanks.
The main beam uses Q690 steel. Side beams are 16 mm to 25 mm high-strength bent plate. The platform is 3 mm to 5 mm chequered plate. Gooseneck reinforcement bars raise effective load capacity. Welded anti-slip ribs keep equipment from sliding. Axles are maintenance free for up to 3 years or 400000 km. Tire sizes include 12R22.5, 315/80R22.5 and 385/65R22.5. Painting is one coat anticorrosive primer plus two topcoats.
This low bed trailer suits construction, mining, forestry and energy projects. Typical loads include excavators, bulldozers, pavers, cranes and rail vehicles. King pin options are 2.0 inch (50 mm) or 3.5 inch (90 mm).
Tell us your cargo weight, deck length and road limits. We will quote a 3 axle low bed semi trailer configuration to match.
| Model Number | Lowbed Semi Trailer |
| Type | Semi-Trailer |
| Max Payload | 60T/80T/100T/150T or Buyer's Request |
| Place Of Origin | China (Mainland) |
| Province | Guangdong |
| Use | Truck Trailer |
| Material | Steel |
| Size | 11500/12500/13000x3000x1750mm or customizable |
| Dimensions | 450 * 228 * 210 |
| Model | Lowbed Semi Trailer |
