80t low bed semi trailer with 5 axles for heavy machinery transport. Customizable deck length and suspension options. Factory pricing available.
The 80t low bed semi trailer is built for transporting heavy construction and mining equipment. This 5-axle configuration distributes weight effectively for stable hauling.
Key specifications include a max payload of 60T, 80T, 100T, or 150T based on your requirements. Standard deck dimensions are 11500/12500/13000 x 3000 x 1750mm, with full customization available. The trailer uses 13/16T heavy-duty axles and a 2.0 or 3.5-inch bolted king pin.
The main beam is constructed from Q690 high-strength steel. Side beams use 16-25mm high-strength plate bending. The platform features a 3-5mm chequered plate with welded anti-slip ribs. These components ensure long-term durability under extreme loads.
Choose between mechanical or air suspension systems. Braking includes a 6 relay valve system, spring brake chamber, and two 45L air tanks. Optional ABS is available. Tire and rim options include multiple sizes to match your operating conditions.
This low bed trailer is ideal for transporting excavators, bulldozers, loaders, pavers, and cranes. It also handles tractors, buses, rail vehicles, and mining machinery. The low deck height improves stability and allows for transporting oversized loads under overhead obstacles.
The ladder is available in manual or hydraulic types. Hydraulic options exceed 60 tons capacity. A spare tire carrier is included as standard. Painting features one coat of anticorrosive primer and two finish coats in your chosen color.
Contact us for detailed specifications and pricing. We support customization based on your exact requirements. Our team provides prompt responses and factory-direct quotes.
| Model Number | Lowbed Semi Trailer |
| Type | Semi-Trailer |
| Max Payload | 60T/80T/100T/150T or Buyer's Request |
| Place Of Origin | China (Mainland) |
| Province | Guangdong |
| Use | Truck Trailer |
| Material | Steel |
| Size | 11500/12500/13000x3000x1750mm or customizable |
| Dimensions | 450 * 228 * 210 |
| Model | Lowbed Semi Trailer |
