100t lowbed semi trailer for heavy machinery. Hydraulic gooseneck, 5 axles, 60-150T load capacity. Factory-direct pricing.
The 100t lowbed semi trailer is built for heavy industrial transport. This hydraulic lowboy moves machinery, containers, and oversized equipment with ease. It meets the needs of demanding logistics operations.
It supports payloads from 60T to 150T. Choose 3, 4, or 5 axles. Deck length ranges from 11,500 mm to 13,000 mm. Width is 3,000 mm. Tare weight ranges from 8,000 kg to 12,800 kg. All dimensions are customizable.
The 100t lowbed semi trailer uses Q690 high-strength steel. Side beams use 16-25 mm bent plate. The platform is 3-5 mm chequered steel. A hydraulic gooseneck makes loading er. Air or mechanical suspension is available. The braking system has six relay valves and two 45L air tanks. Kingpin options are 2.0 or 3.5 inches bolted type. A manual or hydraulic ladder is available. Two spare tire carriers come standard. ABS is optional. The platform has welded anti-slip ribs.
It works for construction, mining, and logistics. It carries excavators, bulldozers, and cranes. It also transports buses, tractors, and rail vehicles. The low deck clears overhead obstacles. A lower center of gravity improves stability. It suits ultra-high loads and rough terrain.
We customize specs to your operation. Contact us for factory pricing and delivery options.
| Model Number | Lowbed Semi Trailer |
| Type | Semi-Trailer |
| Max Payload | 60T/80T/100T/150T or Buyer's Request |
| Place Of Origin | China (Mainland) |
| Province | Guangdong |
| Use | Truck Trailer |
| Material | Steel |
| Size | 11500/12500/13000x3000x1750mm or customizable |
| Dimensions | 450 * 228 * 210 |
| Model | Lowbed Semi Trailer |
